Magnum Pro 100SG Spool Gun
Magnum Pro 100SG Spool Gun

Magnum® PRO 100SG Spool Gun - 4 Pin, 10ft (3.0 m)

K3269-1

Magnum PRO 100SG Spool Gun is low cost for precise feeding of soft aluminum wire.

MSRP

USD $400.24/EA

DETAILS

LIGHT, COMPACT AND RELIABLE WELDING GUNS

The Magnum® PRO 100SG spool gun is the lowest cost way to add reliable and precise wire feeding performance for soft aluminum wire. It's easy to set up for occasional and experienced welders on Lincoln Electric compact wire feeder/welders.

  • Premium Magnum® PRO Expendables - Copper Plus - contact tips and long-life diffusers with Anti-Seize™ threads.
  • Lightweight - at only 3.5 lbs. (1.6 kg).
  • For all aluminum alloys - Recommended wire diameters can be fed with the same drive roll and liner assembly.
  • Ergonomic grip - and balanced design.
  • Full travel mechanical trigger - Excellent feedback even through a welding glove.
  • 10 ft. (3.0 m) gun cable - Gun connector offers fast connections to the welding machine.
  • No expensive gun or bulky adapter module
  • Sturdy carrying case - Protects the gun during transport and storage

Features

  • Lightweight and easy to use
  • Ergonomic grip and balanced design
  • Excellent trigger feedback, even through a welding glove
  • No bulky adapter module required
  • Premium Magnum® PRO expendable gun parts improve heat dissipation and extend life

What's Included

    • Spool gun with 10 ft. (3.0 m) cable
    • Spool of 0.035 in. (0.9 mm) 4043 aluminum alloy wire ED030308
    • 0.030-0.035 in. (0.8-0.9 mm) drive roll
    • Contact tips (Qty. 3) KP2744-035T
    • Electrical harness with toggle switch (must be installed in power source)
    • Sturdy carrying case

You May Also Need

Specifications

MIG/TIG Guns

Length (ft) 10
Rated Amperage CO2 130
Duty Cycle at Rated Amperage (CO2) 30%

Warranty

Warranty 90 Days
